ICEA S-61-402 AAC ACSR Conductor 15KV 25KV ABC Power Cable
ICEA S-61-402 AAC ACSR Conductor 15KV 25KV ABC Power Cable
Contact Now

ICEA S-61-402 AAC ACSR Conductor 15KV 25KV ABC Power Cable

Minimum Order Quantity : 1000 Meter/M Price : US $1-50 / Meters | 1000 Meter/Meters (Min. Order)
Packaging Details : Wooden drum , steel drum
Place of Origin: Henan, China (Mainland) Brand Name: CN
Model Number: ABC cable

Detail Information
Insulation Material: XLPE Application: Overhead
Conductor Material: Aluminum Jacket: XLPE
Rated Voltage: 15KV ,25KV,35KV Conductor: Al/Al Alloy/Cu
Certificate: ISO9001/ISO14001 Standard: IEC60502-2, BS 6622, NFC 33226, Etc.
Package: Wooden Reel, Iron-wooden Reel, Steel Reel Color: Black
High Light:

25KV ABC Power Cable

,

ACSR Conductor ABC Power Cable

,

ICEA S-61-402 ABC Power Cable

Product Description

15KV/25KV/35KV TREE WIRE with AAC/ACSR Conductor according to ICEA S-61-402

Application

The cable is used for primary and secondary overhead distribution where limited space is available or desirable for rights of way.

It is installed as a bare conductor. Covering is effective in preventing direct shorts and instantaneous flashovers should tree limbs or other objects contact conductors. Particularly useful in congested areas such as alleyways or tight corridors.
Applicable Standard

ASTM B230,ASTM B231,ASTM B232

ASTM B398,ASTM B399,ASTM B400
Cable construction AAC/AAAC/ACSR Conductor , XLPE/ Insulation , HDPE Outer Jacket
Packing Material Wooden Reel, Iron-wooden Reel, Steel Reel





Tree Wire-15KV-2Layer-ACSR Core

Size Stranding No. Conductor dia. Insulation thickness Outer sheath thickness Approx. Cable. Dia. Approx. Cable Weight Rated strength
AWG/kcmil No.s mm mm mm mm kg/km KN
4 6/1 6.35 1.9 1.9 14.0 202 7.9
2 6/1 8.03 1.9 1.9 15.6 274 12
1/0 6/1 10.11 1.9 1.9 17.7 379 18.5
2/0 6/1 11.35 1.9 1.9 19.0 451 22.4
3/0 6/1 12.75 1.9 1.9 20.4 539 28
4/0 6/1 14.30 1.9 1.9 21.9 643 35.3
266.8 18/1 15.47 1.9 1.9 23.1 656 29.1
266.8 26/7 16.31 1.9 1.9 23.9 673 47.7
336.4 26/7 18.29 1.9 1.9 25.9 826 59.5
336.4 30/7 18.82 1.9 1.9 26.4 924 73.1
397.5 24/7 19.61 1.9 1.9 27.2 906 61.7
397.5 26/7 19.89 1.9 1.9 27.5 960 68.8
477 26/7 21.79 1.9 1.9 29.4 1134 82.3
477 30/7 22.43 1.9 1.9 30.0 1271 100.5
556.5 24/7 23.22 1.9 1.9 30.8 1232 83.6
556.5 26/7 23.55 1.9 1.9 31.2 1307 95.4
636 24/7 24.82 1.9 1.9 32.4 1393 92.9
636 26/7 25.15 1.9 1.9 32.8 1478 106.4
795 26/7 28.14 2.0 1.9 36.3 1836 133
795 45/7 27.00 2.0 2.0 35.1 1534

93.3





Tree Wire-15KV-2Layer-AAC Core

Size Stranding No. Conductor dia. Insulation thickness Outer sheath thickness Approx. Cable. Dia. Approx. Cable Weight Rated strength
AWG/kcmil No.s mm mm mm mm kg/km KN
1/0 7 8.53 1.9 1.9 16.2 292 8
2/0 7 9.55 1.9 1.9 17.2 342 10
3/0 7 10.74 1.9 1.9 18.4 405 12.2
4/0 7 12.07 1.9 1.9 19.7 484 15.3
266.8 19 13.64 1.9 1.9 21.3 576 19.9
336.4 19 15.32 1.9 1.9 22.9 693 24.6
397.5 19 16.74 1.9 1.9 24.4 796 28.4
477 19 18.34 1.9 1.9 26.0 927 33.4
556.5 37 19.81 1.9 1.9 27.4 1054 39.8
636 37 21.21 1.9 1.9 28.8 1182 45.6





Tree Wire-15KV-3Layer-ACSR Core

Size Stranding No. Conductor dia. Conductor Shield Thickness Insulation thickness Outer sheath thickness Approx. Cable. Dia. Approx. Cable Weight Rated strength
AWG/kcmil No.s mm mils mm mm mm kg/km KN
4 6/1 6.35 0.4 1.9 1.9 14.7 225 7.9
2 6/1 8.03 0.4 1.9 1.9 16.4 301 12
1/0 6/1 10.11 0.4 1.9 1.9 18.5 414 18.5
2/0 6/1 11.35 0.4 1.9 1.9 19.7 491 22.4
3/0 6/1 12.75 0.4 1.9 1.9 21.1 585 28
4/0 6/1 14.30 0.4 1.9 1.9 22.7 701 35.3
266.8 18/1 15.47 0.4 1.9 1.9 23.9 705 29.1
266.8 26/7 16.31 0.4 1.9 1.9 24.7 823 47.7
336.4 18/1 17.37 0.4 1.9 1.9 25.8 848 36.7
336.4 26/7 18.29 0.4 1.9 1.9 26.7 996 59.5
336.4 30/7 18.82 0.4 1.9 1.9 27.2 1391 73.1
397.5 18/1 18.87 0.4 1.9 1.9 27.3 972 42
397.5 24/7 19.61 0.4 1.9 1.9 28.0 1052 61.7
397.5 26/7 19.89 0.4 1.9 1.9 28.3 1146 68.8
477 24/7 21.49 0.4 1.9 1.9 29.9 1226 72.6
477 26/7 21.79 0.4 1.9 1.9 30.2 1338 82.3
477 30/7 22.43 0.4 1.9 1.9 30.8 1896 100.5
556.5 18/1 22.33 0.5 1.9 1.9 31.0 1301 57.9
556.5 24/7 23.22 0.5 1.9 1.9 31.9 1412 83.6
556.5 26/7 23.55 0.5 1.9 1.9 32.2 1542 95.4
636 18/1 23.88 0.5 1.9 1.9 32.5 1786 66.3
636 26/7 25.15 0.5 1.9 1.9 33.8 2043 106.4
