EPR Insulation Type 63 1.9 3.3KV Cable SANS 1520-1 Flexible Trailing Cables

Minimum Order Quantity :	1000m	Price :	$0.3 - $20/ Meter
Packaging Details :	Roll/Wooden Reel/Iron-wooden Reel/Steel Reel	Delivery Time :	1-4 weeks
Payment Terms :	L/C, T/T, Western Union

Place of Origin:	Henan, China	Brand Name:	CN Cale Group
Certification:	ISO9001, CE	Model Number:	Type 63 Mine Cable

Detail Information
Features:	Abrasion , Tear Resistant And Flame Retardant.	Cable Type:	Type 63 1,9/3,3 KV To SANS 1520-1
Conductor:	Tinned Annealed Copper Wires	Insulation:	EPR
Insulation Screen:	The Braid Of Tinned Copper Wires.	Standard:	SANS1520-1
High Light:	Type 63 1.9 3.3KV Cable , EPR Insulation 1.9 3.3KV Cable , SANS 1520-1 Flexible Trailing Cables

Product Description

EPR Insulation Type 63 1.9/3.3KV Cable SANS 1520-1 Flexible Trailing Cables

Product Description

1.Application
Electrically driven machines, movable electric apparatus in hazardous areas. Stackers , shearers , conveyor systems. Suitable for reeling purposes.

Other industrial applications.

2.Applicable Standard
SANS 1520-1

3.Cable Construction:
-Conductor: Flexible class 5 comply to SANS 1411 - 1 from tinned annealed copper wires left lay
-Insulation: Ethylene propylene thermosetting compound type RD 3 comply to SANS 1411-3

-Cable assembly: Three tinned copper braided screened power cores and three unscreened pilot
cores one in each interstice laid up in the right hand lay around semi-conductive cradle centre .

-Reinforcing braid: An open nylon braid . Minimum 16 of nylon strings.

-Outer sheath: Poly-chloroprene thermosetting compound type RS 6 comply to SANS 1411-3 .
Inner and outer sheath are bonded to provide proper torsional protection , black .

Data sheet

Physical Properties
Power cores
Conductor sizes (mm2)	25	35	50	70	95	120	150	185	240
Maximum wire diameter ( mm)	0.41	0.41	0.41	0.51	0.51	0.51	0.51	0.51	0.51
Approx. conductor diameter ( mm)	6.8	8.5	10.3	11.9	13.5	15.5	17.3	20.2	22.9
Maximum screen wire diameter (mm)	0.31	0.31	0.31	0.31	0.31	0.31	0.31	0.31	0.31
Braided screen filling factor (%)	80	80	80	80	80	80	80	80	80
Approx. summarized screen cross-section for power cores (weighing method) (mm2)	31	33	38	42	47	50	55	60	64
Pilot cores
Conductor sizes ( mm2)	10	10	16	16	16	16	16	25	25
Maximum wire diameter ( mm)	0.41	0.41	0.41	0.41	0.41	0.41	0.41	0.41	0.41
Approx. conductor diameter ( mm)	4.2	4.2	5.3	5.3	5.3	5.3	6.8	6.8	6.8
Lay Ratio (maximum) (x PCD)	8	8	8	8	8	8	8	8	8
Cable diameter
Approx. (mm)	44	48	50.5	56	61	63	66	72	78
Cable mass (approx.) (kg/m)	3.6	4.2	4.4	6.4	7.7	8.5	10.5	11.4	14.0
Minimum bending radius (mm)	280	290	310	350	370	380	400	440	480
Maximum recommended tension (kN)	1.1	1.6	2.3	3.2	4.3	5.4	6.8	8.3	10.8

Packing&Shipping

Packing material:

Coil (For small size & short length), Wooden Drum, Iron-Wooden Drum, Steel Drum.

Shipping:

Loading port from Qingdao or Shanghai, 12-24 hours from facotry to sea port.
