2500MCM AAAC All Aluminium Alloy Conductor IEC61089 Standard
Contact Person : Andrea
Phone Number : 0086-371-60547601
WhatsApp : +8613598873045
Detail Information |
|||
Insulation Material: | N/A | Type: | High Voltage |
---|---|---|---|
Application: | Overhead | Conductor Material: | Aluminum |
Jacket: | N/A | Product Name: | China Factory AAAC Cable All Aluminium-alloy Bare Conductor |
Voltage: | High/Medium/Low Voltage | Conductor: | Aluminium-alloy |
Construction: | Concentrically Stranded | Standard: | IEC61089,ASTM B-399,BS3242,NFC 34125 |
Package: | Wooden Reel, Iron-wooden Reel, Steel Reel | ||
High Light: | custom control cables,special power cable |
Product Description
Application:
AAAC conductor is used for overhead distribution and transmission lines adjacent to ocean coastlines.
Applicable Standard:
IEC61089,ASTM B-399,BS3242,NFC 34125
Production Scope:
Max. Size 2500MCM, Max. str. No. 91Wires
Construction:
Concentrically stranded
Cross-section Area | Stranding No. & Wire No.s | Approx. Overall Dia. | Approx. Weight | Rated strength | Max. D.C. resistance at 20℃ | |
mm2 | No.s | mm | mm | Kg/km | kN | Ω/km |
18.4 | 7 | 1.83 | 5.49 | 50.4 | 5.43 | 1.7896 |
28.8 | 7 | 2.29 | 6.87 | 78.7 | 8.49 | 1.1453 |
46.0 | 7 | 2.89 | 8.67 | 125.9 | 13.58 | 0.7158 |
72.5 | 7 | 3.36 | 10.08 | 198.3 | 21.39 | 0.4545 |
115.0 | 19 | 2.78 | 13.90 | 316.3 | 33.95 | 0.2877 |
144.0 | 19 | 3.10 | 15.50 | 395.4 | 42.44 | 0.2302 |
184.0 | 19 | 3.51 | 17.55 | 506.1 | 54.32 | 0.1798 |
230.0 | 19 | 3.93 | 19.65 | 632.7 | 67.91 | 0.1439 |
288.0 | 19 | 4.39 | 21.95 | 790.8 | 84.68 | 0.1151 |
363.0 | 37 | 3.53 | 24.71 | 998.9 | 106.95 | 0.0916 |
460.0 | 37 | 3.98 | 27.86 | 1268.4 | 135.81 | 0.0721 |
518.0 | 37 | 4.22 | 29.54 | 1426.9 | 152.79 | 0.0641 |
575.0 | 37 | 4.45 | 31.15 | 1585.5 | 169. 76 | 0.0577 |
645.0 | 61 | 3.67 | 33.03 | 1778.4 | 190.14 | 0.0516 |
725.0 | 61 | 3.89 | 35.01 | 2000.7 | 213.90 | 0.0458 |
817.0 | 61 | 4.13 | 37.17 | 2254.8 | 241.07 | 0.0407 |
921.0 | 61 | 4.38 | 39.42 | 2540.6 | 271.62 | 0.0361 |
1036.0 | 91 | 3.81 | 41.91 | 2861.1 | 305.58 | 0.0321 |
1151.0 | 91 | 4.01 | 44.11 | 3179.0 | 339.53 | 0.0289 |
1289.0 | 91 | 4.25 | 46.75 | 3560.5 | 380.27 | 0.0258 |
1439.0 | 91 | 4.49 | 49.39 | 3973.7 | 424.41 | 0.0231 |
